Specifications
- Power output socket：9-channel (8-way controlled+1-way uncontrolled), compatible with the national, European, American, and British standard plugs of 1
- Total power limit capacity：~180V ~250V/45A
- Main power input wiring：Air switch * 1, standard configuration 3 * 4mm (three-core national standard power cord is about 1.2m)
- Control interface：1 RS23 2 serial port, 1 wire control interface
- Input power supply：AC220V 50Hz
- Voltage indicator：0-300V
- Sequential time delay：1s
- Dimension (W × D × H)：484mm×280mm×58mm
- Weight：4.8kg
Features
►The input of the air switch is connected to a timing controller.
►The aviation grade high-precision input voltage pointer meter is equipped.
►On the panel, 8-channel output independent control buttons and 8-channel output status indicator lights are equipped to achieve a series of functions, including individual opening, closing of any one channel of output, a timing switch, and a main power control switch.
►There are central control and device level joint control interfaces in the device.
►In addition, the sequencer modes can be infinitely cascaded.
