VT212
Dual 12” Two-way Bi-amp Line Array Speaker
Application: Conference halls, banquet halls, auditoriums, churches, stadiums, touring show
Specifications
- System Type: Dual 12” Two-way Bi-amp Line Array Speaker
- Frequency Response: 60Hz–18kHz (±3dB) / 54.5Hz–18kHz (-10dB)
- Sensitivity (1W/1m): HF: 113.6dB LF: 102dB
- Nominal Impedance: HF: 16Ω LF: 16Ω
- Rated Power (AES): HF: 100W LF: 700W
- Crossover: 900Hz
- HF Driver: 1 × 4" (100mm voice coil)
- LF Driver: 2 × 12" (75mm voice coil)
- Dispersion (H×V): 100° × 10°
- Maximum SPL (Continuous/Peak): HF: 130.8dB / 142.2dB; LF: 127.4dB / 137.1dB
- Connectors: 2 × 4-pin sockets, HF: 2+ 2-, LF: 1+ 1-
- Dimensions (W×D×H): 936 × 570 × 405.8 mm
Features
The VT212 is a compact and lightweight line array loudspeaker. It utilizes new high-quality 12” bass drivers, and its superior dynamic energy minimizes distortion during high-power operation. It employs a 4” high-frequency compression driver paired with a high-precision linear acoustic wavefront horn with 100° horizontal and 10° vertical dispersion, achieving precise and uniform acoustic coverage and ensuring optimal acoustic consistency within the listening area.
The cabinet surface features a durable and wear-resistant spray finish and is equipped with two ergonomically optimized handles. It can be used flown or stacked.
